i2goSignals

goSignals is a security signals processor that provides the ability to route Security Events between systems. A Security Event is a token that describes an event that has occurred within the domain of an issuer. A Security Event Token RFC8417 is a specialized type of Json Web Token traditionally used in OAuth2 based authentication and authorization systems. Typically a series of “SET” tokens are shared in a series called a stream between a publisher and receiver. The management of these streams is defined by the OpenID Shared Signals Events Framework. The mechanism for the transfer of Security Event Tokens is defined by the SET Event transfer protocols (RFC8935 and RFC8936).

The goSignals server works as a gateway router or store and forward server connecting one or more security event generators to one or more receivers across domains using streams. An goSignals server is able to receive, validate, route, and forward Security Event Tokens (SETs) in streams to registered receivers.

The i2goSignals server has the following capabilities:

• Implementation of both SET PUSH (RFC8935) and SET POLL (RFC8936) Protocols
• Organizes SETS into streams between publishers (event generators) and receivers (as defined in RFC8935/8936).
• Support for multiple inbound and outbound streams and routing between them
• Acts as a protocol converter such as enabling Receivers that support Poll transfer only (e.g. from behind a firewall) to pick up events from SET Push-only transmitters.
• Support for fault-tolerant stream recovery including automatic re-transmission and stream resets as well as configurable stream resets to a specified date or event identifier (JTI).
• Supports routing which controls how events are forwarded, and/or re-published to one or more outbound streams
• Validates events based on configured stream signing and encryption requirements.

The i2goSignals project is currently under development and is published for feedback and community involvement at this time. This preview code is not yet ready for production. Key features such as administration API security, multi-node co-ordination and TLS are still in progress.

There are 3 main components to this project

• goSet - utility functions to create SET tokens (which are a profile of JWT tokens) and a set of convenience methods to add, validate, and parse events. Includes support for SCIM Events.
• cmd/goSignalsServer - provides a services framework to implement push and pull delivery services. This framework depends on MongoDB to store configuration and key data. SSEF also uses Kafka to pick up and store event streams per registered stream.
• cmd/goSignalsTool - A command line tool which can be used to configure and administrator an goSignals server.

Getting Started

Clone or download the codebase from GitHub to your local machine and install the following prerequisites.

• Go 1.21.5 - Note: in GoLand make sure to select the correct version of go Preferences > Go > GOROOT.
• Docker Desktop for local testing and development

cd /home/user/workspace/
git clone git@github.com:i2-open/i2gosignals.git

To run the demonstration configuration, see Demonstration Set Up below.

Building a local docker image (starting from the main project directory):

go install ./...
docker build . --tag i2gosignals

[!NOTE] The 0.7.0 release image is also available at ghcr.io/i2-open/i2gosignals:0.7.0

This project uses MongoDB for event, key, and stream storage, management, and recovery. By default, unit testing is done with the MongoDb server defined in docker-compose.yml.

The use of Mongo can be changed out to other database systems. However at this time, it would depend on contributors to implement or sponsor such support.

Run the i2goSignals server and Mongo database using docker-compose

Documentation

• goSignals administration tool
• Supported environment properties

Demonstration Set Up

in the file docker-compose.yml is a sample set up that demonstrates both Push and Pull stream scenarios between 2 separate i2goSignals servers. Additionally, 2 i2scim.io servers are used to demonstrate multi-master replication using SCIM defined provisioning events.

To configure the demonstration do the following:

1. Build the goSignals project (see above)
2. In /ect/hosts or your localdns configuration, define goSignals1 and goSignals2 to point to the corresponding goSignals server in docker (e.g. 127.0.0.1).
3. Start all servocers in docker-compose.yml
4. Start the goSignals tool and perform the following configuration

   To be completed.


Developing and debugging inside Docker (GoLand/JetBrains)

Use the dev stack to run goSignalsServer under the Delve debugger in Docker so you can attach from GoLand or IntelliJ with the Go plugin.

Prerequisites:

• Docker Desktop running
• GoLand or IntelliJ IDEA Ultimate with Go plugin

Start the dev stack with the debug-enabled service:

# Build the dev image (installs Delve)
make dev-build-image

# Start Mongo, Prometheus, Grafana, and goSignals1 under Delve
make dev-up

# Follow logs if desired
make dev-logs

Notes:

• The dev image is defined in Dockerfile-dev and started by docker-compose-dev.yml.
• The project source is volume-mounted into the container at /app. Delve recompiles the server inside the container, so first start may take a little longer while modules download.
• Ports exposed:
  • 8888: application API/UI
  • 2345: Delve debug port

Attach the debugger from JetBrains (GoLand/IntelliJ):

1. Run > Edit Configurations… > add “Go Remote”.
2. Set Host to localhost and Port to 2345.
3. Open “Paths mapping” and add a mapping from your local project root to /app (container path).
4. Click Debug to attach. Set breakpoints in server code under cmd/goSignalsServer or packages it uses.

Iterating:

# Rebuild the dev image (if Dockerfile-dev changed) and restart just goSignals1
make dev-rebuild

# Stop the dev stack
make dev-down

Production image builds are unchanged; continue to use ./build.sh to create the normal release image i2gosignals:<tag> and docker-compose.yml for the full demo stack.
